I really enjoyed reading The Making of Prince of Persia by Jordan Mechner, who was keeping detailed journals of his game development journey.

One of the first computer games I have encountered on a PC was an MS DOS version of Prince of Persia. I have not played it for 30+ years, but the image of protagonist falling to his death and being impaled by spikes at the bottom of the pit still stands vividly before my eyes.

What does it have to do with microbenchmarks? Well, that's the very same image that stands before my eyes when I hear that somebody fell into the very same microbenchmarking trap I have been warning about for as long as I have been writing posts for my blog.

That is even more surprising in todays age of clankers. They will gladly take care of minutiae of HOW for you as long as you remember to ask the right question (and make sure to check the result).

With microbenchmarks, as I have written before, the right question is not whether a measurement produced by the benchmark A is larger or smaller than a measurement produced by benchmark B, but rather WHY these numbers are the way they are. Deriving decisions from numbers without knowing the reason hiding behind these numbers will invariably lead to incorrect conclusions.

Few days ago I saw a post from Filip Hráček comparing execution speed of different Dart loops. As I was scrolling through the text a few things jumped out at me:

We treat the system as a black box and try to make conclusions about its internals purely from a singular measurement.
Benchmarks are not adversarial enough to produce meaningful data.
A huge gap between AOT and JIT performance is mentioned at the end of the post but left without interpretation.

The system is not a black box

The first mistake that the post makes is that it tries to declare whether something is optimized or not purely based on a single number that comes out of the benchmark. It's like trying to reconstruct my commute route from the time it took me to reach Copenhagen from Aarhus. If I tell you it took me 12 hours you probably decide that I biked... while in reality I drove but my car broke several times on the way and I had to walk and take public transport for the last stretch.

Don't try to divine whether or not something is optimized by looking at single number. You do not have to do that. The system is open - you can actually look at the generated code and figure it out from there. There many different ways to do it, the simplest of them being something like this:

$ dart compile exe -v                                              \
    --extra-gen-snapshot-options=--print-flow-graph-optimized      \
    --extra-gen-snapshot-options=--disassemble-optimized           \
    --extra-gen-snapshot-options=--code-comments                   \
    --extra-gen-snapshot-options=--print-flow-graph-filter=FILTER ...

It's also a good idea to look at the CPU profile collected using perf, simpleperf, Instruments or whatever tool you like to see where the code is actually spending time - then you will immediately know whether your benchmark is actually measuring what you think it is measuring.

Benchmarks must be adversarial

It is also well understood that these systems are so complex that they don't always exhibit stable behavior even after warmup, see Virtual Machine Warmup Blows Hot and Cold

It is well understood that to measure peak performance of a dynamically optimized system you must include warmup into your benchmark. It is well understood that you need to make it harder for compiler to throw the whole benchmark away as dead code But that's just a tip of the iceberg.

To write good benchmarks you need to understand more about underlying execution layers. Classical example of that is that benchmarking binary search by repeating binarySearch(list, item) vs repeating binarySearch(list, randomItems[i]) will produce two different numbers. Why? Branch prediction. By repeating the same search again and again we allow CPU to keep hitting the streak of successful predictions, randomizing input data throws a wrench into this machinery, saturates the predictor and allows us to see a completely different picture.

When micro-benchmarking high-level programming languages be it Dart or JavaScript you need to have at least some understanding of underlying cost model for core operations that your benchmark performs. What is the baseline cost of these operations as dictated by language semantics? What is execution environment doing to reduce this cost? Can it fail?

Well, the rabbit hole of course goes deeper because the cost of that ldr depends on other factors, like whether or not it hits the CPU cache.

In C an array access a[i] is just a pointer dereference *(a + i), there is nothing complicated going behind the scenes - it's just an ldr or mov instruction at the end. In Dart a[i] is a method call a.operator[](i). How that method call ends up executing on the CPU depends on the execution mode (native JIT/AOT, JS, Wasm) and what compiler knows about your program.

Take a look at this program:

@pragma('vm:never-inline')
int foo(List<int> list) => list[0];

@pragma('vm:never-inline')
int bar(List<int> list) => list[0];

@pragma('vm:never-inline')
int baz(List<int> list) => list[0];

@pragma('vm:never-inline')
int quux(List<int> list) => list[0];

void main(List<String> args) {
  repeat(() {
    foo(List.filled(10, 0, growable: true));
    bar(List.filled(10, 0, growable: false));
    baz(List.filled(10, 0, growable: args.contains('--baz-growable')));
    quux(List.filled(10, 0, growable: true));
    quux(List.filled(10, 0, growable: false));
  });
}

On Dart VM in JIT mode after warmup:

JIT specializes code by using inline caches to record concrete classes observed by individual callsites.

foo will be a speculative direct access to a growable list, effectively equivalent to:

deoptIfNot(list, growableListCid);
checkBound(list->length, index);
return *(list->data + elementOffset(index))

bar will be speculative direct access to non-growable list:

deoptIfNot(list, fixedLengthListCid);
checkBound(list->length, index);
return *(list + elementOffset(index))

baz will be the same as either foo or bar depending on the command line args

quux will be polymorphically inlined version that contains both possibilities:

if (classId(list) == growableListCid) {
  checkBound(list->length, index);
  result = *(list->data + elementOffset(index));
} else {
  deoptIfNot(list, fixedLengthList);
  checkBound(list->length, index);
  result = *(list + elementOffset(index));
}
return result;

In AOT mode this will be different:

AOT specializes code by performing a global type flow analysis - it's a static analysis so inferred information is approximate.

foo will be a direct access to a growable list at fixed index:

checkBound(list->length, 0);
return *(list->data + elementOffset(0))

bar will be a direct access to non-growable list at a fixed index:

checkBound(list->length, 0);
return *(list + elementOffset(0))

baz and quux will be the same: an indirect call via a global dispatch table (GDT)
```
return GDT[list->cid + selectorOffset(List.operator[])](list);
```

Obviously the underlying costs are very different between these, so a benchmark that is written without taking this into account will provide data which does not cover the full spectrum of possibilities.

Doubt Everything

13 years ago in Lisbon at LXJS I gave my very first talk about microbenchmarking. There I referred to René Descartes and his philosophy of Cartesian doubt.

Descartes was not so much into microbenchmarking himself, but if he were he would certainly write some good ones:

It is some years now since I realized how many false opinions I had accepted as true from childhood onwards, and that, whatever I had since built on such shaky foundations, could only be highly doubtful. Hence I saw that at some stage in my life the whole structure would have to be utterly demolished, and that I should have to begin again from the bottom up if I wished to construct something lasting and unshakeable in the sciences.

First Mediation

In the case of Filip's loop benchmark even ignoring everything else I have said above the huge gap between JIT and AOT should have immediately ignited the red lamp of doubt. The alarm bells should have started ringing and benchmark should have been examined closer with appropriate tools.

Just employ a clanker

The truth here is that I feel a tiny bit redundant writing all of this because you don't have to be me and know Dart AOT compiler flags by heart or endure my preaching about methodology. You can just employ a clanker. I think it is probably a mistake to not to. They are rather good at building and using tools and you can always double check what they came up with or steer them back into the right thing if they go off rails.

I have tried two things:

Ask it to look at the benchmark and tell me why AOT performs worse than JIT. It came back with exactly the same answer I got manually. The issue is fairly trivial so no surprise here - at the current stage I would be more surprised if it failed to figure it out. It did end up using my SDK checkout to do it rather than using installed SDK, so may be it is an argument for wiring these options more prominently into dart compile exe.
Ask it to build me a command line tool for profiling on Mac OS and use to profile the benchmark. It did it - and the result highlighted the same problem which can be quickly glimpsed by inspecting compiler IL. On Linux you can just ask it to use perf and it will do that. But I always wanted a CLI alternative to Instruments but never bothered to write things.

Of course clankers can get confused, but at the very least you can employ them to make you tools to get all necessary data out and then review the data (and the tools) yourself.

Back to Benchmark itself

Start by dumping benchmark IL:

$ dart compile exe -DLOOP_VARIANT=for-loop -v                  \
  --extra-gen-snapshot-options=--print-flow-graph-optimized    \
  --extra-gen-snapshot-options=--print-flow-graph-filter=main_ \
  lib/main.dart

The core loop looks like this:

 14: B7[join]:38 pred(B2, B5) {
      v111 <- phi(v186 T{_Smi}, v118) alive [0, 4611686018427387903] int64 T{<:int}
      v185 <- phi(v153, v117 T{<:num}) alive T{<:num}
}
 15:     ParallelMove fp[-1] <- r5
 16:     CheckStackOverflow:44(stack=0, loop=1)
 18:     v173 <- LoadField(v5 T{_GrowableList} . GrowableObjectArray.length) [0, 576460752303423487] T{_Smi}
 20:     v176 <- UnboxInt64(v173 T{_Smi}) [v173, v173] int64
 22:     Branch if RelationalOp(<, v111, v176 T{_Smi}) T{bool} goto (5, 8)
 24: B5[target]:26
 26:     v123 <- LoadField(v5 T{_GrowableList} . GrowableObjectArray.data) T{_List}
 28:     v187 <- LoadIndexed:32([_List] v123, v111 T{<:int}) [-9223372036854775808, 9223372036854775807] T{<:int}
 30:     v180 <- UnboxInt64(v187 T{<:int}) [-9223372036854775808, 9223372036854775807] int64
 32:     v167 <- BinaryInt64Op(* [tr], v180 T{<:int}, v180 T{<:int}) [-9223372036854775808, 9223372036854775807] int64
 34:     v168 <- BinaryInt64Op(* [tr], v180 T{<:int}, v167) [-9223372036854775808, 9223372036854775807] int64
 36:     v182 <- BoxInt64(v168) [-9223372036854775808, 9223372036854775807] T{<:int}
 38:     v199 <- LoadClassId(v185 T{<:num}) int64
 40:     MoveArgument(sp[1] <- v185 T{<:num})
 42:     MoveArgument(sp[0] <- v182 T{<:int})
 43:     ParallelMove r0 <- r1
 44:     v117 <- DispatchTableCall( cid=v199 num.+<0>, v185 T{<:num}, v182 T{<:int}) T{<:num}
 45:     ParallelMove r1 <- r0, r0 <- fp[-1]
 46:     v118 <- BinaryInt64Op(+ [tr], v111 T{<:int}, v188 T{_Smi}) [1, v176] int64
 48:     ParallelMove r5 <- r5, r4 <- r1, r2 <- fp[-3], r3 <- fp[-2] goto:42 B7

From which we can conclude that:

num sum = 0;
for (var i = 0; i < list.length; i++) {
  sum += pow(list[i], 3);
}

Ended up doing a method call to compute sum + pow(...) instead of doing simple integer arithmetic. If we profile this code we will discover that it spends most of the time (85%) in the runtime system adding 64-bit integers in the slowest way possible.

This fundamentally means that the benchmark is not measuring what it intended to measure and instead measuring something else entirely.

This can be trivially fixed by avoid num type altogether, which is something that we always recommend anyway: num is a type which mixes two completely different numeric types: 64-bit integer and double precision floating point number. These types can't be efficiently operated upon in a uniform fashion so it is better to avoid it.

int sum = 0;
for (var i = 0; i < list.length; i++) {
  sum += pow(list[i], 3) as int;
}

Fixing this aligns JIT and AOT performance on the baseline test (for-loop) and reveals performance differences between different loop styles which were previously hiding in the shadow of a much bigger performance problem, e.g. for-in-indexed is around 2.5-3x slower in this particular benchmark, after adjusting the code a bit to avoid extremely expensive doNotOptimize(...) which again was hiding actual costs.

If we look back at what I have said above in Benchmarks must be adversarial and update the benchmark to include obscure the underlying type of the list being iterated:

// Compile no longer knows if list is growable or non-growable. VM does not
// have uniform representation for these.
final list = List<int>.generate(kListSize, (i) => i, growable: !args.contains('fixed'));

Then we discover that:

for-loop iterating over a list instance of unknown concrete type is roughly 5x slower than for-loop iterating over a list which is known to the compiler to be a built-in growable list.
for-loop iterating over a list instance of unknown concrete type is roughly 1.5x faster than for-in-indexed over a list instance of unknown concrete type.
for-each iterating over a list instance of unknown concrete type is actually 25% faster than for-loop over a list instance of unknown concrete type, which reverses the relationship between these two.

We could explore more things here (e.g. look at how dart2js or dart2wasm deal with this), but I think you get the message: don't just look at one number, it is meaningless by itself. Look at many numbers, look at the code and profiles.

And probably ask your clanker to help you with that.
